Packaging Artwork and Dielines: Getting Files Right the First Time
Artwork is the part of a launch that feels finished long before it is. The design looks right on screen, the brand approves it, and then the printer returns a list of objections. Each round costs days, and the days come directly out of the production window. Almost all of the friction comes from a small set of avoidable issues.
Start From the Dieline, Not From a Mock-up
A dieline is the technical drawing of a pack's flat shape: cut lines, fold lines, glue areas, and the registration marks for the print process. Every supplier can provide one for their component. Building artwork on a dieline supplied by the factory, rather than on a photograph or a competitor's pack, eliminates the first category of rework. For a tube, the dieline also fixes the seam position and the crimp area, both of which are invisible in a mock-up and obvious on a finished tube.
Bleed, Safe Area and Trim
Three zones govern where content may sit. Bleed extends beyond the cut so that minor misregistration does not produce a white edge, typically a few millimetres. Trim is the cut itself. The safe area sits inside the trim and is the only place text and key graphics should appear. Layouts that push a logo to the trim edge look confident on a screen and lose a sliver of the letterform on the print run.
Colour: Build, Profile and Spot
Cosmetic packaging is printed in CMYK on most substrates, sometimes with spot colours for brand accuracy and sometimes with white under-print on clear or dark material. Two problems recur:
- RGB files. An RGB file converted carelessly at the printer can shift saturated oranges, deep purples and bright greens significantly. Convert deliberately and check the result on a proof.
- Brand colour drift. If the brand colour must be exact across several components made by different suppliers, specify a spot colour and give the reference, rather than trusting a CMYK build to reproduce consistently on coated board, uncoated board and a plastic tube.
Legal Panels and Curved Surfaces
The legal panel is where artwork meets regulation, and it is where layouts most often fail. The nominal content, ingredient list in the required order, usage or warning statements, batch and best-before placement, responsible person details and country of origin all need space. Two practical realities: on a small jar or a slim tube the panel occupies far more area than the designer expects, and on a cylindrical surface the usable width is narrower than the circumference suggests because the edges curve away. Set the panel first, then design around it, not the reverse.
Barcodes, QR Codes and Minimum Size
A barcode that scans unreliably costs a listing. Respect the minimum size for the symbology, keep a quiet zone of clear space around it, avoid placing it over a curved or glossy area without a matte panel behind it, and check the contrast. For QR codes, test the printed code at the actual size on the actual substrate; a code that works on a screen at 100 percent often fails on a curved tube. Remember that a QR code linking to a product page also needs to keep working for the life of the pack.
File Formats, Layers and Versions
Supply layered files, keep text live where possible, and keep the dieline on its own layer so the printer can toggle it. Name files with the product, the pack size and a revision number, and keep a change log. Artwork without a revision history is artwork that will eventually be printed from the wrong version.
Proofing Before the Run
A digital proof confirms layout and content but not colour or substrate behaviour. A press proof on the actual material is the only reliable check for colour, metallic effects, white under-print and finish. For a first order, a press proof on the main component is worth the time. It is also the cheapest moment to catch a problem: after the run, correcting artwork means reprinting, and on a decorated pack that can exceed the original print cost.
Where Multiple Suppliers Touch the Same Artwork
A range that uses a tube, a jar and a carton often means three printers working from three dielines, and consistency becomes the brand's problem rather than any one supplier's. Two disciplines prevent drift. Keep a single master artwork file with the brand's colour references and typography, and issue each printer only the version relevant to their component. Then set one person, inside the brand or inside the manufacturing partner, as the only route by which artwork changes are approved. When several people can send a revised file directly to a printer, version control collapses within a month and the resulting inconsistency shows up on shelf next to a competitor's uniform range.
Timing Artwork Into the Schedule
Artwork sits on the critical path. Allow for design, internal review, regulatory review, printer preflight, proof approval and, realistically, one round of corrections. Brands that finalise artwork while the formula is still in stability testing launch on time. Brands that start artwork after the formula is approved add three to four weeks that nothing else can absorb. OEM COSMETICS ODM supplies dielines for every offered component, reviews submitted artwork against the legal panel requirements of the destination market, and coordinates preflight with the printer so the revision count stays at one.
